INDUSTRIAL SWEEPERS FOR EVERY JOB
• 80 Gallon Sprinkler System
• Two-Post ROPS Canopy
• Rear Fenders
• Positive Neutral Start
• Hydraulic Power Steering
• Hydraulic Drum Rear Towing Brakes
• Mechanical Parking Brake
• Gear Motor Final Drive
• P205 75R14 4-Ply Radials
• Automotive-Style Tow Hitch. Includes Surge Brakes, Towing Lights and Wiring Harness
• All Polyethylene Brush, all Steel Wire Brush, or 1/2 and 1/2
• Choice of 2” or 2-5/16” ball hitch, or 3” pintle hitches
• Greasable Front Wheel Spindle
• Omaha Orange Paint
• Steel Broom Core
• Front Debris Deflector
• 9 Gallon Fuel Tank w/Mechanical Gauge
• Cushioned Seat with 2” Retractable Seat Belt & Arm Rests
• Reverse Alarm
• Electric Hour Meter
• Hydraulic Sight Gauge
• Warning Light Package, Engine Oil Pressure, Water Temperature and Alternator
• Engine Protection System
• Hub-Engaged Warning System
LAY-MOR 8HC | |
---|---|
Engine | KUBOTA V1505 diesel 37, HP |
Broom size | 6-3/8" I.D x 24" O.D |
Broom angle | 40° (each way) |
Steering | 45° (each way) |
Speed | 0 to 7.5 mph |
LAY-MOR SM300 | |
---|---|
Engine | KUBOTA D1105 Tier Final |
Broom size | 6.375" I.D x 24" O.D |
Broom angle | 40° (fully angled) |
Steering | 45° (fully angled) |
Speed | 0 to 7.5 mph |
Height | 7'6" |
Transport length | 14' |
BROCE BW-260 | |
---|---|
Operating Weight | 3200LBS |
Horsepower | 24 HP |
Emission Rating | Tier 4 Final |
Sweeping Width | 8FT |
Engine Make/Model | Kubota V1505 |
Rated Speed | 2300rpm |
Net Tourque | 68LBF/FT |
Displacement | 91in3 |
Transmission Type | Hydrostatic Pump |
Max Forward Speed | 10mph |
Tire Size | 205/75-14 |
Brake Type | 2-Wheel Hydraulic Drum |
Outside Turning Radius | 5FT |
Fuel Tank Capacity | 9 GAL |
Length | 12FT 6IN |
Transport Width | 8FT |
Height to Top of Cab | 7FT 10IN |
Broom Width | 8FT |
Broom Drive | Single Hydraulic Motor |
Brush Speed | 192 RPM |
Broom Angle | Full 40° (both directions) |
Water Sprinkler System | 72 GAL |
