HYDRAULIC HAMMER RENTALS
WHEN YOU NEED HIGH IMPACT STRENGTH TO BREAK THROUGH ROCK & DIG HOLES, YOU CAN COUNT ON HYDRAULIC HAMMERS FROM EASY RENT ALL. WE CARRY DEPENDABLE, NAME BRAND EARTH MOVING ATTACHMENTS FOR EXCAVATORS & SKID STEERS.
HYDRAULIC HAMMER RENTALS NEAR ME
QUICK MENU
HYDRAULIC HAMMER RENTALS NEAR ME
EPIROC EC-120
Essential Casing hydraulic breaker for excavators of 15-24 tons (33,000-53,000 lb)
THIS ATTACHMENT IS AVAILABLE FOR THE 👉 VOLVO EC140EL 👈
List of Services
-
Hybrid TechnologyList Item 1
Integrated nitrogen piston accumulator for constantly high impact energy, safe start-up and smooth operation
-
VibroSilenced PlusList Item 2
Non-metallic suspension arrangements to isolate percussion mechanism from breaker box and sealing of all openings for lower noise and vibration levels
-
Advanced Control TechnologyList Item 3
The integrated control valve optimizes efficiency; the EnergyRecovery system increases operating efficiency and lowers vibrations
-
Monoblock DesignList Item 4
Combined cylinder & tool holder section eliminating the need for tie rods for higher reliability; replaceable piston liner for cost-effective repairs
-
Percussion Chamber Ventilation
The built-in check valve reduces dust intake into the tool guiding area and the percussion chamber
-
StrokeControl Valve
The combined stroke length and start-up mode switching valve enables the operator to adjust the breaker operation mode to the application for optimum performance
-
ContiLubeTM II
Optional self-bleeding automatic lubrication device for optimized grease consumption and continuous lubrication
-
Field Replaceable Bushing
Full length floating tool bushing for quick exchange with standard hand tools
| Epiroc EC-120 | |
|---|---|
| Carrier weight class ¹ | 33 000 lb - 53 000 lb |
| Service weight ² | 2,650 lbs |
| Oil Flow | 32 gpm - 37 gpm |
| Operating pressure | 2,175 psi - 2,465 psi |
| Max. hydraulic input power | 53 hp |
| Impact rate AutoStop mode | 550 bpm - 720 bpm |
| Tool diameter | 120 mm |
| Sound power level, guaranteed ³ | 121 dB(A) |
HYDRAULIC HAMMER RENTALS NEAR ME
ALLIED 355E
Versatile and efficient Rammer 355E is your everyday partner for carriers between 1.1 and 3.6 tons. The 150 kg hammer is protected by box type housing and produces less noise and vibration, whilst is strong enough to take a beating. The Rammer 355E comes with the remote monitoring hardware RD3 installed.
THIS ATTACHMENT IS AVAILABLE FOR THE 👉 KUBOTA U27-4 & KUBOTA KX033-4 👈
List of Services
-
Tubular AccumulatorList Item 2
The leak-free tubular accumulator is filled with nitrogen and requires no maintenance or time-consuming recharging between maintenance intervals.
With its large surface area and short hydraulic connections to the piston, it effectively reduces pressure fluctuations in the hydraulic system and ensures maximum piston acceleration and high impact frequency.
This design provides 100% power at all times.
-
CBE+ (Constant Blow Energy)
The RAMMER CBE-System (CBE = Constant Blow Energy) with the active pressure control valve and the permanently filled tubular accumulator maintains the hydraulic pressure level to ensure that each impact delivers the maximum possible power.
The RAMMER CBE system accepts a wide range of oil flows and high back pressures, allowing a wide range of carriers to be used.
The "+" stands for safe and fast connection to the carrier.
-
Vibration & Sound SuppressionList Item 3
Less vibrations and at the same time significantly lower noise levels are achieved with this ultra-modern, low-wear design.
This protects the operator, the carrier and relieves the environment.
This extends your range of applications on narrow job sites and wherever noise protection is required.
-
Twin HandedList Item 1
The twin handed design allows optimal mounting on both left and right handed carriers, prolonging the service life of the hose connections.
Easy installation for hydraulic quick hitch mounting brackets.
-
Single Part Tube Bushing
The one-piece quick-change tool bushing inludes a thrust ring, the upper and the lower tool bushing into one component.
This quick-change tool bushing can easily be replaced on site, making maintenance easier, faster and safer.
-
No Tie Rods
A smart design without tie rods allows for ideal guidance of the piston and optimal alignment of the tool.
Fast, safe and easy to maintain without the need for special tools.
-
RD3 - My Fleet
RD3 for MyFleet as standard. Online hour meter and location tracking in Google MapsTM.
-
Flange MountingList Item 4
The Flange mounting design allows for the use of existing mounting plates, as well as carrier and application specific customization.
-
Quick Change Tool System
Quick and safe tool change system transverse to the hammer. No need to reach under the hammer during tool change.
| Allied 355E | |
|---|---|
| Minimum working weight, flange mounted *1 | 330 lb |
| Weight | 270 lb |
| Working length | 37.2 in |
| Impact rate (frequency) | 800 - 3000 bpm |
| Operating pressure | 1305 - 2175 psi |
| Oil flow range | 6.6 - 14.5 gal/min |
| Pressure relief setting *2 | 2175 - 2900 psi |
| Pressure relief max | 3190 psi |
| Pressure in LP-circuit | 550 - 580 psi |
| Back pressure max | 290 psi |
| Input power | 19 hp |
| Tool diameter | 48 mm |
| Pressure line connection (IN) | BSPP-internal 1/2" |
| Return line connection (OUT) | BSPP-internal 1/2" |
| Pressure line size, min. inner diameter | 0.47 in |
| Return line size, min. inner diameter | 0.47 in |
| Optimum oil temperature | 104 - 140 °F |
| Allowed oil temperature range | -4 - 176 °F |
| Optimum oil viscosity at operating temperature | 30 - 60 cSt |
| Allowed viscosity range | 20 - 1000 cSt |
| Skid steer, robot weight, optimum | 2900 - 4600 lb |
| Skid steer, robot weight, range *3 | 2400 - 5300 lb |
| Miniexcavator weight, optimum | 4200 - 6800 lb |
| Miniexcavator weight, range *3 | 3500 - 7900 lb |
| Noise level, measured (2000/14/EC) | 114 dB(A) |
| Noise level, guaranteed (2000/14/EC) | 118 dB(A) |
HYDRAULIC HAMMER RENTALS NEAR ME
EPIROC SB-52
Solid Body Breakers are perfect for demolishing light concrete structures and asphalt pavements, both outdoors and indoors, performing earthworks, scaling in underground operations, and cleaning ladles and converters in foundries.
THIS ATTACHMENT IS AVAILABLE FOR THE 👉 Hitachi ZX60-5 Kubota K008-3 Kubota KX71-3 Kubota KX033-4 Kubota U27-4 Sherpa 100 ECO 👈
List of Services
-
SolidBody ConceptList Item 2
Integrates percussion mechanism and guide system into a single block of special cast iron, decrasing the total number of parts. It also eliminates components like damping and guiding elements and tie rods or stud bolts completely and results in an extremely slim and copmact shape to simplify handling. A replaceable piston liner supports low repair cost.
-
Energy Recovery
The piston recoil energy is automatically utilized to increase the performance without additional hydraulic input and to lower vibrations.
-
Air & Water InletList Item 3
To connect compressed air supply and an integrated water channel for dust suppression (for SB 152 -SB 1102, water nozzles as option)
-
Floating BushingList Item 1
Tool bushing with floating fit for easy exchange on-site with standard hand tools
-
Dust Wiper
Integrated dust wiper to extend service life of bushing and retainer bars
-
Auto Start
AutoStart
The hydraulic breaker starts without load applied to working tool thus simplifying handling
| EPIROC SB-52 | |
|---|---|
| Carrier weight class ¹ | 1 550 lb - 2 400 lb |
| Service weight ² | 120 lb |
| Working tool diameter | 1,57 inch |
| Working length of tool | 10 inch |
| Hydraulic input power, max | 9,1 HP |
| Oil flow | 3,2 gpm - 7,1 gpm |
| Operating pressure | 1 450 psi - 2 175 psi |
| Impact rate | 750 blows/min - 1 700 blows/min |
| Sound power level, guaranteed ³ | 117 dB(A) |
HYDRAULIC HAMMER RENTALS NEAR ME
EPIROC SBU 220
A solid body breaker is manufactured from a single block of cast metal. The Epiroc SBU 220 has an integrated percussion mechanism and guide system and is designed without side bolts for maximum reliability. Featuring compact design for easy positioning, lower vibration and less noise, few parts and easy maintenance.
THIS ATTACHMENT IS AVAILABLE FOR THE 👉 VOLVO EC60E 👈
| EPIROC SBU 220 | |
|---|---|
| Carrier weight class ¹ | 6 000 lb - 13 000 lb |
| Service weight ² | 500 lb |
| Working tool diameter | 2,56 inch |
| Working length of tool | 12 inch |
| Hydraulic input power, max | 25 HP |
| Oil flow | 11,1 gpm - 19,8 gpm |
| Operating pressure | 1,450 psi - 2,175 psi |
| Impact rate | 750 blows/min - 1 700 blows/min |
| Sound power level, guaranteed | 118 dB(A) |
| 12 inch | |
| Hydraulic input power, max | |
| 25 HP | |
| Oil flow | |
| 11,1 gpm - 19,8 gpm | |
| Operating pressure | |
| 1 450 psi - 2 175 psi | |
| Impact rate | |
| 750 blows/min - 1 400 blows/min | |
| Sound power level, guaranteed ³ | |
| 118 dB(A) |
HYDRAULIC HAMMER RENTALS NEAR ME
ALLIED AR 130B
The Model 130 AR Series hydraulic hammer offers reliable performance, minimum maintenance and an attractive price which makes this hammer the perfect match for the rental industry and contractors breaking rock and demolishing concrete. The AR 130 is a 3,900 pound hydraulic hammer that mounts easily on a 44,000 to 76,000 pound excavator. Built with high quality materials that guarantee long service life, the AR 130 is simple and easy to service. No special tools are needed for maintenance, no parts are attached to the box and there are no side plate bolts or cross rods to break.
THIS ATTACHMENT IS AVAILABLE FOR THE 👉 SANY SY215C VOLVO EC220DL 👈
List of Services
-
Optimum PerformanceList Item 1
Proven design with an optimum combination of weight, power and performance
-
Quick StartList Item 2
Easy start with minimal down-pressure allows operation in any position
-
Full-Box EnclosureList Item 3
Full-box enclosure protects the tool holder and allows raking of boulders
-
Easy MaintenanceList Item 4
No special tools are needed for maintenance or disassembly
-
Shock-Absorbing Inserts
Shock-absorbing polyurethane inserts reduce shock to the carrier and dampen noise
-
AutoLube II™
Options include AutoLube II™, Underwater Kits and VMS mounting kits
| Allied AR 130B | |
|---|---|
| Mounting Type | MCS |
| Frequency | 350-470 bpm |
| Hydraulic Flow Required | 32-43 gpm |
| Hydraulic Pressure | 1,950-2,250 psi |
| Working Weight | 3,900 lbs |
| Overall Length | 109 in |
| Standard Demolition Too | Cross-Cut |
| Tool Diameter | 5.12 in |
| Recommended Carrier Weigh | 44,000-76,000 lbs |
| Energy Rating | 2,400 ft. lbs |
| Frequency | 396 bpm |
| Hydraulic Flow | 42.9 gpm |
| Supply Pressure | 2,182 psi |
